Norsat 1108DHN Simultaneous Ku Band LNB with +/-10kHz PLL LO Stability
$3,938.60 AUD
The Norsat 1108DHN-2 Simultaneous Ku Band LNB with +/-10 kHz PLL LO Stability provides simultaneous downconversion of the full Ku band (10.95-12.75GHz) in a single LNB and provides the L Band output in two stages 950-1700MHz (L) & 950-2000MHz (H) via separate N type 50Ω connectors. Click Here to contact us for a quotation.
Description
Description
The Norsat 1108DHN-2 Simultaneous Ku Band LNB with +/-10 kHz PLL LO Stability provides simultaneous downconversion of the full Ku band (10.95-12.75GHz) in a single LNB and provides the L Band output in two stages 950-1700MHz (L) & 950-2000MHz (H) via separate N type 50Ω connectors.
The Norsat 1108DHN-2 Simultaneous Ku Band LNB with +/-10kHz PLL LO Stability utilises two local oscillators, 9.75GHz for the low band and 10.75GHz for the high band. The Norsat 1108DHN-2 Simultaneous Ku Band LNB utilises an internal phase lock looped reference to provide a local oscillator stability of +/-10kHz.
| Norsat 1108DHN-2 KEY SPECIFICATIONS | |
|---|---|
| Band | Ku-Band |
| Input Frequency Band 1 | Ku-band:10.95 – 11.7 GHz(L); 11.7 -12.75 GHz(H) |
| Lo Stability | +/- 10 kHz |
| Lo Type | PLL |
| Noise Figure | 0.8 dB |
| Output Frequency 1 | L-Band: 950 – 1700 MHz(L); 950-2000 MHz(H) |
| Product Family | 1000 Series |
| Norsat 1108DHN-2 RF SPECIFICATIONS | |
|---|---|
| Conversion Gain | 55 dB typ |
| Input VSWR | 2.2 : 1 |
| Lo Frequency 1 | 10.00 GHz(L); 10.75 GHz(H) |
| Output VSWR | 2.0 : 1 |
| Norsat 1108DHN-2 INTERFACE SPECIFICATIONS | |
|---|---|
| RF Input Connector | WR-75 waveguide grooved |
| RF Output Connector | N-50 Ohm |
| Norsat 1108DHN-2 ENVIRONMENTAL SPECIFICATIONS | |
|---|---|
| Temperature Operational | -40 to +60°C |
Norsat’s Low Noise Blocks (LNBs) provide signal reception for satellite communications around the world. Norsat offer premium performance and reliability in the smallest form factor possible. All of Norsat’s standard LNBs are backed by a 1 year warranty and nearly forty years of experience as the industry’s leading provider of high performance LNBs.
Additional information
Additional information
| Weight | 1.5 kg |
|---|---|
| Dimensions | 15 × 10 × 10 cm |
| Frequency Band | |
| SKU | LN1108DHN |
