NJT8336 is a Ku-band block up-converter of 14 to 14.5 GHz and transmits the amplified RF signals of up to 16W (+42 dBm) of linear output power, in an ultra-compact weatherproof enclosure with forced air cooling.
NJT8336 is a Ku-band block up-converter of 14 to 14.5 GHz and transmits the amplified RF signals of up to 16W (+42 dBm) of linear output power, in an ultra-compact weatherproof enclosure with forced air cooling.
This BUC is designed for the block up-converter intended for the satellite communication data uplink application in Ku-band. It can transmit an RF signal (Ku-band: 14.0 to 14.5 GHz or 13.75 to 14.5 GHz) output with up to 16W (+42 dBm) linear operation. It is combined a high power GaN HEMT and linearizer for higher power linear output, and a block up-converter with a phase locked local oscillator (13.05 GHz or 12.8 GHz) which is synchronized with external 10MHz reference.
It is operated by +24 V / +48 V DC power (Range: +18 to +54 V) input via either Circular Connector or IF Connector. The BUC can support the monitor and control functions by either Ethernet interface with both HTTP protocol of web browser and SNMP v2c protocol or RS-485 (or RS-232C option) interface with NISD original protocol. The BUC comes in a single, weatherized housing rated for outdoor use and has either an N-Type or F-type female connector as IF input, a WR-75 waveguide flange as RF output.
The BUC receives a reference signal (10 MHz) and an IF signal (L‐band: 950 to1,450 MHz or 950 to 1,700 MHz) input and transmits an RF signal (Ku-band: 14.0 to 14.5 GHz or 13.75 to 14.5 GHz) output. It is operated by +48 V DC power (Range: +36
to +54 V) input via either Circular Connector or IF Connector. The BUC can support the monitor and control functions by either Ethernet interface with both HTTP protocol of web browser and SNMP v2c protocol or RS-485 (or RS-232C option) interface with NISD original protocol. The BUC comes in a single, weatherized housing rated for outdoor use and has either an N-Type or F-type female connector as IF input, a WR-75 waveguide flange as RF output.
Parameter | Value |
Frequency Organisation | RF Frequency: 14.0 to 14.5 GHz IF Frequency: 950 to 1,450 MHz LO Frequency: 13.05 GHz |
8W(+39dBm) Linear Output Power / High Efficiency & Low Distortion Output Power |
Rated Output Power: +42 dBm +42 dBm typ. for -26 dBc ACPR / Spectrum Regrowth +41 dBm typ. for -30 dBc ACPR / Spectrum Regrowth Power Consumption: 110W typ., 115W max. (+36 to +54 VDC) |
Excellent Receive Band Rejection Filter Equipped | -156 dBm/Hz max. @ 10.95 to 12.75 GHz |
Supporting High Operation Temperature | Operating Guarantee Temperature Range: -40 to +75 ℃ |
Various M&C Interface Support | Ethernet (HTTP / SNMP) RS-485 / RS-232 (Option) Parallel I/O |
Small Size & Light Weight | Weight: 1.8 kg |
Others | LED Indicator Equipped RoHS Compliance |
Weight | 2 kg |
---|---|
Dimensions | 16 × 84 × 9 cm |
SKU | BNJT8336 |
