M2 S-Band Satellite Dish Feedhorn 2100-2400 MHz
The 2100-2400 MHz Septum Dish Feed offers many advantages over standard feed assemblies.
Description
Description
The 2100-2400 MHz Septum Dish Feed offers many advantages over standard feed assemblies. The 2100-2400 MHz Septum Dish Feed has an extremely compact element design and has very good isolation between both LHC and RHC ports.
Currently three frequencies are available, but the feed is scalable for your custom application. Custom spar leg mounts are also available for your specific dish size. Contact M2 Antenna Systems, Inc. with your requirements and we will help you put together a complete turnkey system
The 2100-2400 MHz Septum Dish Feed offers many advantages over standard feed assemblies. The 2100-2400MHz Septum Dish Feed has an extremely compact element design and has very good isolation between both LHC and RHC ports. Currently three frequencies are available, but the feed is scalable for your custom application. Custom spar leg mounts are also available for your specific dish size.
Key Features
| Parameter | Value |
| Model Number | FGFD-1-SC-2-N |
| Frequency Coverage | 2100-2400 MHz |
| Optimum Dish Feed F/D Ratio |
0.3 TO 0.45 |
| System Efficiency | 50 TO 65% |
| Isolation Between Ports (L-Band) |
<30 dB |
| Ellipticity | 2.0 DB |
| Polarity | RHC / LHC |
| Connector | “N” Female |
Additional information
Additional information
| Weight | 8 kg |
|---|---|
| Dimensions | 46 × 36 cm |
| SKU | M2FGFD-1-SC-2-N |
