Coaxial Switch C Band 3.5-4.2GHz
This Coaxial Switch supported C Band frequencies in the 3.5-4.2GHz range and is used to switch Tx and Rx distribution systems that use coaxial interfaces. This Coaxial Switch C Band 3.5-4.2GHz can be supplied with N type or SMA type 50 ohm connectors and can be operated manually or in electrically controlled automatic switching systems.…
Description
Description
This Coaxial Switch supported C Band frequencies in the 3.5-4.2GHz range and is used to switch Tx and Rx distribution systems that use coaxial interfaces.
This Coaxial Switch C Band 3.5-4.2GHz can be supplied with N type or SMA type 50 ohm connectors and can be operated manually or in electrically controlled automatic switching systems. This type of Coaxial Switch is often used in redundancy setups to support automatic switched between active and backup RF components such as upconverters, downconverters, LNB/LNAs, etc.
Coaxial Switch C Band 3.5-4.2GHz Operating Frequencies
- DC – 2.0 GHz (option)
- 1.0 – 3.0 GHz (option)
- 3.5 – 4.2 GHz
- 5.85 – 8.2 GHz (option)
Key Features
| Parameter | Value |
| Return Loss | -18dB Min |
| Isolation | 60dB Min |
| Insertion Loss | .25dB Max |
| Driving Voltage | Optional |
| C-Form Contacts | Optional |
| Inhibit Contacts | Optional |
| Switching Time | 60 Msec Max |
| Power Connector | Optional |
| Coax Connectors | N-Type or SMA |
| Material | 80% Aluminium |
| Finish | Lusteron on Waveguide, Anodize on Driver |
| Operating Temp | -40° to +75°C |
| Non- Operating Temp | -50°T0 +100°C |
| Humidity | 100% |
