Baird B4-6×6 Non-Penetrating Mount (NPM) for 1.2m Dishes

Description

The Baird B4-6×6 Non-Penetrating Mount (NPM) with 73mm (2.8″ OD) Mounting Pole is designed to provide a rigid and stable mount for ground and roof-top site installations. The Baird B4-6×6 Non-Penetrating Mount (NPM) with 73mm (2.88″ OD) Mounting Pole is commonly used with 1.2m satellite antennas, microwave antennas, wireless antennas, and other applications.
The Baird B4-6×6 Non-Penetrating Mount (NPM) with 73mm Mounting Pole is typically used with the following models of GD Satcom Prodelin 1.2m satellite dish;

• GD Satcom Prodelin 1123 Series Satellite Dish
• GD Satcom Prodelin 1132 Series Satellite Dish
• GD Satcom Prodelin 1134 Series Satellite Dish
• GD Satcom Prodelin 1135 Series Satellite Dish
• GD Satcom Prodelin 1891 Series Satellite Dish
• GD Satcom Prodelin 1892 Series Satellite Dish
• GD Satcom Prodelin 1983 Series Satellite Dish
• GD Satcom Prodelin 1984 Series Satellite Dish
• GD Satcom Prodelin 1985 Series Satellite Dish

The Baird B4-6×6 Non-Penetrating Mount (NPM) with 73mm Mounting Pole can also be used to mount terrestrial antennas and ODUs with masts available up to 3 metres.
Baird has built an enviable reputation over the last 25 years, by providing the best mounting systems in every market they serve. Baird products have become legendary for withstanding the most demanding environmental conditions on earth. Baird Non-Penetrating Mounts (NPM) provide a rapid installation capability by allowing satellite dishes and antennas to be installed without being permanently attached to the roof top or ground substrate. Baird NPMs spread the weight and antenna wind loads over a large surface area minimising loads on the substrate typically to within general construction design limits allowing almost any flat surface to accept satellite dishes up to 3.8m. STEP Electronics provide a ballast calculation service to advise how much ballast should be added to an NPM for a given location and antenna size to withstand the Australian wind category rating for that area.
